Interactive Graphics with Shiny

Shiny

These slides modified from https://github.com/dime-wb-trainings/shiny-training

What Is Shiny?

Shiny is a web application framework for R that allows you to turn analyses into interactive web apps — all in R.

Why use it?

• Easy to learn and use
• Fast development cycle
• Powerful for data visualization
• Built on R (leverage your analysis directly)
• Great for sharing insights interactively

Anatomy of a Shiny App

A Shiny app has two core components:

• UI (User Interface): Defines how the app looks
• Server: Defines how the app works

The Client, Host, and Server

Apps are served to users via a host and port. The R session running the server reacts to user actions, computes results, and sends them back.

Client: The web browser where the user interacts with the app

Host:Port: Shiny app is served at an IP (host) and port

Server: Runs R session to monitor inputs and respond with outputs

Let’s Build Our First App Together (with the help of the R template) ✍️

Step-by-step instructions:

1. Open RStudio
2. If you haven’t already installed Shiny, run:

install.packages("shiny")

3. Load the Shiny library:

library(shiny)

4. Create a new Shiny Web App: Click on File > New File > R Shiny Web App

Let’s Build Our First App Together (with the help of the R template) ✍️

5. Choose Single File option when prompted:

6. Name your folder and click OK

7. Click Run App in the top-right corner

8. 🎉 You’re running your first Shiny app!

Let’s Explore the Code 🧠

ui — User Interface

ui <- fluidPage( #<<
  titlePanel("Old Faithful Geyser Data"),
  sidebarLayout(
    sidebarPanel(
      sliderInput("bins",
                  "Number of bins:",
                  min = 1,
                  max = 50,
                  value = 30)
    ),
    mainPanel(
      plotOutput("distPlot")
    )
  )
)

Layout elements

• fluidPage() is the container for the app interface, the layout in which your content is. This is the most common, but there are other types of layouts. Check here

ui — User Interface

ui <- fluidPage(
  titlePanel("Old Faithful Geyser Data"),
  sidebarLayout( #<<
    sidebarPanel(
      sliderInput("bins",
                  "Number of bins:",
                  min = 1,
                  max = 50,
                  value = 30)
    ),
    mainPanel(
      plotOutput("distPlot")
    )
  )
)

Layout elements

• sidebarLayout() splits the layout into sidebar (sidebarPanel()) and main area (mainPanel()). This is also optional.

ui — User Interface

ui <- fluidPage(
  titlePanel("Old Faithful Geyser Data"),
  sidebarLayout(
    sidebarPanel( #<<
      sliderInput("bins",  #<<
                  "Number of bins:",  #<<
                  min = 1, #<<
                  max = 50, #<<
                  value = 30) #<<
    ),
    mainPanel(
      plotOutput("distPlot")
    )
  )
)

Page content

• sidebarPanel() contains one input field (sliderInput()) called “bins”. This is a slider that lets a user choose a number. As you can infer from the name, in this case, it’s the number of histogram bins.

ui — User Interface

ui <- fluidPage(
  titlePanel("Old Faithful Geyser Data"),
  sidebarLayout(
    sidebarPanel(
      sliderInput("bins",
                  "Number of bins:",
                  min = 1,
                  max = 50,
                  value = 30)
    ),
    mainPanel( #<<
      plotOutput("distPlot") #<<
    )
  )
)

Page content

• mainPanel() contains a histogram (plotOutput()), which will be defined in the server function. The name, or id, of this histogram is “distPlot”

Shiny server Logic Explained ⚙️

server <- function(input, output) {
...
}

The server() function takes two arguments:

• input: a reactive list of input values from the UI
• output: a reactive list where you assign render functions

Reactive lists are “special” lists used in reactive programming — a way to make your app automatically update outputs when inputs change.

Shiny server Logic Explained ⚙️

server <- function(input, output) {
  output$outputId <- renderFunction({
    value <- input$inputId
})
}

Let’s take a look at reactivity inside a simple server( ):

• renderFunction: A function like renderPlot(), renderTable(), etc. used to render an output (a plot, a table…)
• outputId: Identifies the rendered output in the output list (output$) for the UI
• The function regenerates value every time the input field referenced by inputID in the input list changes.

Shiny server Logic Explained ⚙️

server <- function(input, output) {
  output$distPlot <- renderPlot({
    x <- faithful[, 2]
    bins <- seq(min(x), max(x), length.out = input$bins + 1)

    hist(x, breaks = bins, col = 'darkgray', border = 'white',
         xlab = 'Waiting time to next eruption (in mins)',
         main = 'Histogram of waiting times')
  })
}

In our case:

• the server contains the logic to create the histogram distPlot in the output list (output$), using the render function renderPlot().

• distPlot depends on one user input (input$bins), which pulls the number from the slider input in the UI.

➡️️ Result: the histogram updates as the slider moves!

How the Server Connects to the UI 🧩

Remember these connections?

UI	Server
plotOutput("distPlot")	output$distPlot <- renderPlot()
sliderInput("bins", ...)	input$bins

Inputs & Outputs in Shiny 🧠

Shiny apps are built by connecting inputs (from the UI) to outputs (rendered in the server).

Part	Role	Examples
ui	Define layout and inputs/outputs	sliderInput(), plotOutput()
server	Logic to render outputs based on inputs	renderPlot(), renderText()

🔁 Reactivity connects them:

• input$... pulls values from UI controls
• output$... <- render...() generates dynamic content

A recap on Reactivity 🔁

• Reactive programming lets your app respond to changes without needing to re-run code manually.
• input and output behave like reactive lists — not regular R lists, but special objects in Shiny.
• When a user selects a value on the slider, say 5, Shiny stores it as input$bins = 5.
• If the user changes it to 7, Shiny automatically updates the input list — and any render function using it will re-execute.
• This is why output$distPlot <- renderPlot({ ... input$bins ... }) updates instantly.

Together, input, output, and render*() functions form the reactive backbone of your app.

Common Input Widgets 🛠️️

Shiny includes many built-in widgets to capture user input:

Widget	Purpose	Example Use
numericInput()	Enter a number	Age, price
sliderInput()	Select from a range	Histogram bins
selectInput()	Choose from a list	Country selector
radioButtons()	Choose one option	Plot type
textInput()	Enter text	Comments, filters
fileInput()	Upload a file	CSV, Excel
actionButton()	Trigger an action manually	Run, Submit

📚 See the full gallery: ➡️ Shiny Widgets Gallery

Let’s start with some basic modifications ✍️

1. Change the title of the app
2. Change the number of bins to 20
3. Change the color of the histogram to #ca8dfd (a shade of purple)

Let’s start with some basic modifications ✍️

After your modifications the app should look like this:

• The app with the modifications is available here

Behind the Scenes: Running a Shiny App ⚙️

Before you close the app, check the R console. You’ll see something like:

#> Listening on http://127.0.0.1:3827

🔍 What it means: - 127.0.0.1 refers to your local machine (“localhost”) - 3827 is a random port number - You can open the app in any browser using this address

⛔ While the app is running: - The R console is blocked (no new commands allowed) - A stop sign appears in the RStudio toolbar

🛑 To stop the app: - Click the stop sign icon - Press Esc (or Ctrl + C in terminal) - Close the Shiny app window

Questions

Share your Shiny app

• 🏢 Posit Connect Internal Server
  • Recommended option for secure deployment within the Bank
  • Content is deployed on Bank server behind a firewall, only accessible to Bank employees
• 🌐 Posit Connect Public Server
  • Content is deployed on Bank server behind a firewall, but accessible to all.
  • Only display public use data

For both:

• Push-button publishing from RStudio or publish directly from GitHub

• Request Posit Connect access as a Software Request

• Learn more, Internal Resources

Share your Shiny app

Additional Resources 📚

Want to go further with Shiny? Here are some helpful resources:

• 🧪 Shiny Tutorial (Official Getting Started Guide) here

• 📘 Mastering Shiny by Hadley Wickham (Free online book) here

• 💡 Shiny Widgets Gallery here

• 🧩 Awesome Shiny Extensions (Community plugins) here

• 🌐 Shiny Community (Forums, discussions) here

• 📦 Building Web Applications (Training) here

• 🧱 Adding multiple objects in layout here

Some examples ✨

• Shiny App Gallery here

• California Schools Climate Hazards Dashboard here

• New Zealand Trade Intelligence Dashboard here

• Locating Blood Banks in India here

• Understanding voters’ profile in Brazilian elections here
